Información técnica
Conjunto del cuadro
| Cuadro | Vitae Full Carbon, Boost 12x148mm, Wheel travel: 150mm, Tire clearance 29×2.6 | |
| Horquilla | Rock Shox Lyrik, 150 mm, 15x110mm BOOST | |
| Amortiguador | Rock shox Deluxe Select + | |
| Juego de dirección | Integrated Full Internal Cable Routing |
Transmisión
| Cambio Trasero | Shimano XT 12s |
Frenos
| Conjunto de frenos | Shimano MT520 hydraulic disc 4-Piston, 203mm |
Ruedas
| Cubiertas | Maxxis Rekon 29 x 2.6 TR | |
| Ruedas | DT Swiss M 1900 |
Componentes
| Manillar | Race Face Turbine R | |
| Potencia | Race Face Aeffect | |
| Tija sillín | Megamo telescopic seat post, remote adjustment |
*Megamo se reserva el derecho a modificar cualquier componente, por uno de igual valor en caso de ser necesario, sin previo aviso. |
Geometría VITAE 10 (25)
SML
A
T/T574603638
B
C/S440440440
C
S/T390420455
D
H/T95100115
E
REACH427455487
F
STACK612617631
G
BB OFFSET333333
H
FRONT ANGLE65.5º65.5º65.5º
I
REAR ANGLE76.5º76.5º76.5º
J
WHEEL BASE117912091247
